2000GPM / 135PSI Horizontal Split Case Fire Pump Ductile Cast Iron Materials UL Listed

  • 1
  • 2
  • 3

Brand Name : CNP NM FIRE

Model Number : SCF200-150-460 (8x6")

Certification : UL Listed

Place of Origin : China

MOQ : 1set

Payment Terms : L/C, T/T

Delivery Time : 35-40 Working Days

Packaging Details : Export Package

Price : Negotiation

Color : Red

Casing : Ductile Cast iron

Shaft : AISI 4340

Wear ring : Bronze

Seal : Gland packing

Brand : CNP FIRE

Contact Now

2000GPM / 135PSI Horizontal Split Case Fire Pump Ductile Cast Iron Materials UL Listed
Horizontal Split Case
The protection of life is not a matter for compromise
This is particularly true for fire protection systems where they are only as strong as their 'weakest link' and compromise may result in avoidable loss of life or property. That is why NM fire pumps are designed specifically for the very particular needs of fire protection and are approved by most of the major fire protection bodies around the world. By selecting an approved NM Fire Pump as part of an approved system and maintained in accordance with standards such as NFPA 20, you can sleep easy knowing that you have chosen the best you can get.

Parameters:
HEAD PUMP MODEL SPEED MAX SHAFT POWER
PSI FEET METER RPM HP KW
135 312 95 SCF200-150-460
(8x6")
1800
(60Hz)
286 213.1

Application:

Industrial fields: All petroleum, petrochemical, chemical, oil fields, pipelines bureaus, oil repositories, oil terminals, oil refineries, offshore platforms, etc.; National grain storages, thermal power plants, steel plants, shipyards, paper mills, etc.;

Commercial Field: five-star hotels, hospitals, schools, supermarkets, office buildings, large-scale commercial complex, highway tunnels, subway stations, railway stations, airports; Fire-fighting Engineering Companies;

How It Works:

The most common split case pump is a single-stage, between bearing, non-self-priming centrifugal volute pump. The design of the pump allows for easy removal of the pump’s top casing to enable easy access to the pump’s components without interfering with the motor or the piping system.

The independent bearing casing allows for easy maintenance without the need for removing the pump’s top casing. The pump’s double volute design minimizes the radial load on the shaft, increasing component life and reducing vibrations to provide a quiet operation.


KEY FEATURES
  • Complete compact unit
  • Horizontal
  • Tailored to the customer's required standards and specifications
  • Configuration for NFPA20 / FM / UL up to 4000 US gpm
  • Good suction characteristics, also with higher speeds
  • Practically no limitations on flow
  • Less wear and tear influences
  • Easy maintenance without interfering on piping / driver
  • Select Models Available in alternate materials with FM approval

Performance Ranges:

UL:

Q: 500-4000GPM H:100-190PSI

FM:

Q: 500-4000GPM H:100-190PSI

CCCF:

Q:20-500L/S H:0.42-2.0Mpa

NFPA20:

Q: 300-8000GPM H:60-300PSI

Advantage:

  • We are the first member of NFPA among Chinese pump manufacturers. The production of our fire pump groups is strictly in accordance with NFPA20.
  • We are the first manufacturer in the world who have both UL/FM certification for fire pump and the fire-fighting diesel engine, also the only UL Witness laboratory in Asia for fire-fighting pump and fire-fighting diesel engine.
  • We have applied dozens of patents.
  • We have young team, top experts.

Service:

1. Reply within 24 hours.
2. High-quality products and the most reasonable price
3. Data and chemical technology support.
4. Professional team service
5. Customiszed production for different package
6. No delay on shipment
